MA 60

centre suspension, internal

Internal centre suspension for cable trays (height 60 mm). For tray widths of up to 300 mm.

The centre suspension is not suitable for installation trays.

Continously hot galvanized (Sendzimir process) (DIN EN 10346)

Артикул	Product	height	width	length	Pmax Maximum load
MA 60-10S	56 mm	40 mm	90 mm	0.26 kN	0.26 kg
MA 60-20S	56 mm	40 mm	190 mm	0.26 kN	0.36 kg
MA 60-30S	56 mm	40 mm	290 mm	0.26 kN	0.45 kg
