KHI
bracket support with continuously elongated hole perforation in bars, for brackets type KT, for fastening directly to wall/ceiling with BL 7/BGI
Hot-dip galvanized, according to BS 729 (DIN EN ISO 1461)
| Артикул | Product | height | width | length | weight | |
|---|---|---|---|---|---|---|
| KHI 02F | 80 mm | 42 mm | 200 mm | 1.10 kg | ||
| KHI 03F | 80 mm | 42 mm | 300 mm | 1.70 kg | ||
| KHI 04F | 80 mm | 42 mm | 400 mm | 2.30 kg | ||
| KHI 05F | 80 mm | 42 mm | 500 mm | 2.90 kg | ||
| KHI 06F | 80 mm | 42 mm | 600 mm | 3.50 kg | ||
| KHI 07F | 80 mm | 42 mm | 700 mm | 4.10 kg | ||
| KHI 08F | 80 mm | 42 mm | 800 mm | 4.70 kg | ||
| KHI 09F | 80 mm | 42 mm | 900 mm | 5.30 kg | ||
| KHI 10F | 80 mm | 42 mm | 1000 mm | 5.90 kg | ||
| KHI 11F | 80 mm | 42 mm | 1100 mm | 6.40 kg | ||
| KHI 12F | 80 mm | 42 mm | 1200 mm | 7.10 kg | ||
| KHI 13F | 80 mm | 42 mm | 1300 mm | 7.60 kg | ||
| KHI 14F | 80 mm | 42 mm | 1400 mm | 8.20 kg | ||
| KHI 15F | 80 mm | 42 mm | 1500 mm | 8.80 kg | ||
| KHI 16F | 80 mm | 42 mm | 1600 mm | 9.40 kg | ||
| KHI 17F | 80 mm | 42 mm | 1700 mm | 10 kg | ||
| KHI 18F | 80 mm | 42 mm | 1800 mm | 10.60 kg | ||
| KHI 19F | 80 mm | 42 mm | 1900 mm | 11.10 kg | ||
| KHI 20F | 80 mm | 42 mm | 2000 mm | 11.70 kg | ||
| KHI 21F | 80 mm | 42 mm | 2100 mm | 12.30 kg | ||
| KHI 22F | 80 mm | 42 mm | 2200 mm | 12.90 kg | ||
| KHI 23F | 80 mm | 42 mm | 2300 mm | 13.50 kg | ||
| KHI 24F | 80 mm | 42 mm | 2400 mm | 14.10 kg | ||
| KHI 25F | 80 mm | 42 mm | 2500 mm | 14.60 kg | ||
| KHI 26F | 80 mm | 42 mm | 2600 mm | 15.20 kg | ||
| KHI 27F | 80 mm | 42 mm | 2700 mm | 15.80 kg | ||
| KHI 28F | 80 mm | 42 mm | 2800 mm | 16.30 kg | ||
| KHI 29F | 80 mm | 42 mm | 2900 mm | 16.90 kg | ||
| KHI 30F | 80 mm | 42 mm | 3000 mm | 17.50 kg | ||
| KHI 60F | 80 mm | 42 mm | 6000 mm | 35.10 kg |
